دوربین مداربسته داهوا تحت شبکه دو مگاپیکسل IPC-HDW1230T1-A-S5

Camera
Image Sensor: 1/2.8″ CMOS
Max. Resolution: 1920 (H) × 1080 (V)
ROM: 16 MB
RAM: 64 MB
Scanning System: Progressive
Electronic Shutter Speed: Auto/Manual 1/3 s–1/100,000 s
Min. Illumination
0.01 lux@F2.0 (Color, 30 IRE)
0.001 lux@F2.0 (B/W, 30 IRE)
0 lux (Illuminator on)
S/N Ratio: > 56 dB
Illumination Distance: 30 m (98.43 ft) (IR)
Illuminator On/Off Control: Auto; manual
Illuminator Number: 1 (IR LED)
Pan/Tilt/Rotation Range
Pan: 0°–355°
Tilt: 0°–78°
Rotation: 0°–355°

Lens
Lens Type: Fixed-focal
Lens Mount: M12
Focal Length: 2.8 mm; 3.6 mm
Max. Aperture
2.8 mm: F2.0
3.6 mm: F2.0
Field of View
2.8 mm: Horizontal: 102°; Vertical: 54°; Diagonal: 120°
3.6 mm: Horizontal: 88°; Vertical: 47°; Diagonal: 104°
Iris Control: Fixed
Close Focus Distance
2.8 mm: 0.5 m (1.64 ft)
3.6 mm: 0.8 m (2.62 ft)

Video
Video Compression: H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream)
Smart Codec: Smart H.265+; Smart H.264+
Video Frame Rate
Main stream:
1920 × 1080@1–25/30 fps
Sub stream:
704 × 576@1–25 fps
704 × 480@1–30 fps
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity.
Stream Capability: 2 streams
Resolution: 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)
Bit Rate Control: CBR/VBR
Video Bit Rate
H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps
Day/Night: Auto (ICR)/Color/B/W
BLC: Yes
HLC: Yes
WDR: DWDR
White Balance: Auto; natural; street lamp; outdoor; manual; regional custom
Gain Control: Auto; manual
Noise Reduction: 3D NR
Motion Detection: OFF/ON (4 areas, rectangular)
Region of Interest (RoI): Yes (4 areas)
Smart Illumination: Yes
Image Rotation: 0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower)
Mirror: Yes
Privacy Masking: 4 areas

Audio
Built-in MIC: Yes
Audio Compression: G.711A; G.711Mu; G.726

Alarm
Alarm Event: Network disconnection; IP conflict; illegal access; motion detection; video tampering; audio detection; security exception

Network
Network Port: RJ-45 (10/100 Base-T)
SDK and API: Yes
Cyber Security: Configuration encryption;Trusted execution;Digest;Security logs;Trusted upgrade;WSSE;Trusted boot;Account lockout;Generation and importing of X.509 certification;Video encryption
Network Protocol: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP
Interoperability: ONVIF (Profile S); CGI; P2P; Genetec
User/Host: 6 (Total bandwidth: 36 M)
Storage: FTP
Browser: IE
Chrome: Firefox
Management Software: Smart PSS; DSS; DMSS
Mobile Client: iOS; Android

Certification
Certifications
CE-LVD: EN 62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B

Power
Power Supply: 12 VDC/PoE (802.3af)
Power Consumption
Basic: 1.2 W (12 VDC); 2 W (PoE)
Max. (ICR + H.265 + IR intensity): 3.1 W (12 VDC); 4.1 W (PoE)

Environment
Operating Temperature: –40 °C to +60 °C (–40 °F to +140 °F)
Operating Humidity: ≤ 95%
Storage Temperature: –40 °C to +60 °C (–40 °F to +140 °F)
Protection: IP67

Structure
Casing: Metal + Plastic
Product Dimensions: 85.5 mm × Φ109 mm (3.4″ × Φ4.3″)
Net Weight: 0.24 kg (0.5 lb)
Gross Weight: 0.37 kg (0.8 lb)
