اکستندر 3 پورت Poe اچ آر یو آی HR-POE013-WP

Network Standard

IEEE 802.3、IEEE 802.3u、IEEE 802.3x

Port

3*10/100Mbps RJ45 power supply port1*10/100Mbps RJ45 receiving port
POE Power The whole power is 30WOutput power of single port is 24W, average output power per port is 8W
POE Connection

POE input receiving wire core：1/2+、3/6- 、4/5+、7/8-POE output power supply core：1/2+、3/6-

100M Transmission

Performance

Store and forwardMAC address table 1k

Switching capacity 1.6Gbps

Forwarding Rate 10 BASE-T:14880PPS/port100BASE-tx：148800pps/port
Port Function Power priority mechanism, fast and forward, MAC automaticlearning and aging IEEE802.3X Full-duplex and backpressure for half-duplex mode
Environment Operating Temperature：-10℃ – -55℃
Power Input：DC44-57V，30W；Output：DC44-57V， 24W
Weight & Size 55g95mm×130mm×35mm(L×W×H)
