| Specification |
| I/O Interface |
| Power |
Input: AC 100-240V, 50/60Hz |
| Ethernet |
24 Port 10/100M PoE + 2 Port 1000M Ethernet Uplink+1 Port 1000M SFP |
| Performance |
| Switching Capacity |
10.8Gbps |
| Forwarding Rate |
8.035Mpps |
| Packet Buffer |
1.5Mb |
| MAC Address |
2K |
| Jumbo Frame |
9216bytes |
| Transfer Mode |
Store and forward |
| MTBF |
100000 hours |
| Standard |
| Network protocol |
IEEE802.3, IEEE802.3u, IEEE802.3x, IEEE802.3ab, IEEE802.3ab |
| PoE Protocol |
IEEE802.3af (15.4W) |
| IEEE802.3at (30W) |
| Industry Standard |
EMI: FCC Part 15 CISPR (EN55032) class A |
| EMS: EN61000-4-2 (ESD) |
| EN61000-4-4 (EFT) |
| EN61000-4-5 (Surge) |
| Network Medium |
10BASE-T: Cat 3, 4, 5 UTP(≤100 meter) |
| 100BASE-TX: Cat5 or more UTP (≤100 meter) |
| 1000Base-TX: Cat5 or more UTP/STP(≤100 meter) |
| Optical Media |
Multimode fiber: 50/125, 62.5/125, 100/140um |
| Single mode fiber: 8/125, 8.7/125, 9/125, 10/125um |
| Protection |
| Certificate |
CE, FCC, RoHS |
| Environment |
| Environment |
Working Temperature: -10~50°C |
| Storage Temperature: -40~85°C |
| Working Humidity: 10%~90%，non-condensing |
| Storage Temperature: 5%~90%，non-condensing |
| Working Height: Maximum10,000 feet |
| Storage height: Maximum 10,000 feet |
| Physical Features |
| Dimension |
Product Dimension (L*W*H): 320*207*45mm |
| Package Dimension (L*W*H): 370*290*85mm |
| N.W: 1.9kg |
| G.W: 2.4kg |
| Packing Info |
Carton MEAS: 445*310*390mm |
| Packing Qty: 5 units |
| Packing Weight:13KG |
| Power Voltage |
Input Voltage: AC 100-240 V |
| Power supply: 52V5.76A |
| Package List |
Switch 1 pcs, Power cord 1 pcs, User manual 1 pc, Certification 1 pc, Brackets 1 pair |
| Indicators |
| DIP Switch |
VLAN : Port isolation mode. In this mode, the PoE ports (1-24) of the switch cannot communicate with each other, and can only communicate with the UP-link port |
| OFF: Normal mode, all port can communicate with each other, the transmission distance is within 100 meters, the transmission rate is 10M / 100M adaptive |
| Extend : Link extension mode, 9-24 ports PoE power supply and data transmission distance can be extended to 250 meters, the transmission rate becomes 10M |
| LEDs |
PWR(power supply)，SW(DIP)，1-27(Link&Data) |
